SPECIFICATIONS

ORDERING INFORMATION

6400-E-201108-1000

Worldwide Distribution and Service Network

Distributed by:

JAPAN

CHROMA JAPAN CORP.

472 Nippa-cho, Kouhoku-ku,

Yokohama-shi, Kanagawa,

223-0057 Japan

http://www.chroma.co.jp

E-mail: [email protected]

U.S.A.

CHROMA SYSTEMS

SOLUTIONS, INC.

25612 Commercentre Drive,

Lake Forest, CA 92630-8830

Tel: +1-949-600-6400

Fax: +1-949-600-6401

Toll Free: +1-866-600-6050

http://www.chromausa.com

E-mail: [email protected]

Developed and Manufactured by :

CHROMA ATE INC.

致茂電子股份有限公司

HEADQUARTERS

No. 66, Hwa-Ya 1st Rd.,

Hwa-Ya Technology Park,

Kuei-Shan Hsiang,33383

Taoyuan County, Taiwan

Tel: +886-3-327-9999

Fax: +886-3-327-8898

http://www.chromaate.com

E-mail: [email protected]

EUROPE

CHROMA ATE EUROPE B.V.

Morsestraat 32, 6716 AH Ede,

The Netherlands

Tel: +31-318-648282

Fax: +31-318-648288

http://www.chromaeu.com

E-mail: [email protected]

CHINA

CHROMA ELECTRONICS

(SHENZHEN) CO., LTD.

8F, No.4, Nanyou Tian An

Industrial Estate, Shenzhen,

China PC: 518052

Tel: +86-755-2664-4598

Fax: +86-755-2641-9620

Model

6430

6460

6463

6490

Output / Phase

1 (parallel or series)

1 or 3 selectable

Output Ratings

Power / Phase

3000VA

6000VA

2000VA

3000VA

Voltage
Range / Phase

150V/300V/Auto

150V/300V(parallel),

300V/500V(series)

150V/300V

Accuracy

0.2% + 0.2% of F.S.

Resolution

0.1V

Distortion

0.5% for (45-500Hz),

1% for (> 500-1KHz)

Line Regulation

0.1%

Load Regulation

0.1%

0.2%(series), 0.8% (parallel)

0.2%(3 phases), 0.8% (1 phase) 0.2%(3 phases), 0.8% (1 phase)

Temp. Coefficient

0.02% per ˚C

Max. current -rms / Phase

30A/15A

60A/30A/15A (150V/300V/500V)

20A/10A (150V/300V)

30A/15A ( 150V/300V)

Peak Current/

phase-crest-factor

3(45-100Hz),

2.5(>100-1KHz)

180A/90A/45A (45-100Hz),

150A/75A/38A (>100-1kHz)

60A/30A (45-100Hz),

50A/25A (>100-1kHz)

90A/45A (45-100Hz),

75A/38A (>100-1kHz)

Frequency

Range

45-1000Hz

Accuracy

0.1%

0.15%

Resolution

0.1Hz

0.01Hz (45-99.9Hz), 0.1Hz (100-999.9Hz)

Input Ratings

Voltage Range

190-250V, 1Ø

190-250V, 3Ø

Frequency Range

47-63Hz

Current

23A max.

23A max./phase

15A max./phase

23A max./phase

Power Factor

0.98 min.

0.98 min. under full load

0.97 min. under full load

0.98 min. under full load

Measurement

Voltage / Phase

Range

0-150V/0-300V

Accuracy (rms)

0.25% + 0.1% F.S.

0.25% + 0.1% F.S

Resolution

0.1V

Current / Phase

Range (peak)

0-140A

0-280A

0-100A

0-140A

Accuracy (rms)

0.4% + 0.1% F.S.

0.4% + 0.15% F.S.

0.4% + 0.1% F.S.

Resolution

0.01A

Power / Phase

Range

0-3000W

0-2000W

0-3000W

Accuracy

1% F.S. (CF<6)

Resolution

0.1 W for P<1000W, 1W for

P>1000W

0.01 W

Frequency

Range

45-1000Hz

Accuracy

0.02%

0.01%+2 count

Resolution

0.1Hz

0.01Hz

Others

Efficiency

80% typical

Protection

UVP, OVP, OCP, OPP,

OTP, Short

OPP, OLP, OTP, FAN Fail

Safety & EMC

CE (Include LVD and EMC Requirement)

Dimension (H x W x D)

221.5 x 425 x 567 mm /

8.72 x 16.73 x 22.32 inch

765.94 x 546 x 700 mm /

30.16 x 21.5 x 27.56 inch*1

990 x 546 x 700 mm /

38.98 x 21.5 x 27.56 inch*1

990 x 546 x 700 mm /

38.98 x 21.5 x 27.56 inch*1

Weight

27 kg / 59.47 lbs

107 kg / 235.68 lbs

156 kg / 343.61 lbs

Note*1 : For dimension including the wheel set, please add 80mm to overall height.

6404 : Programmable AC Source 0~300V / 45~500Hz / 375VA

6408-1: Programmable AC Source 0~300V / 45~500Hz / 800VA (input rating 90-132V)

6408-2 : Programmable AC Source 0~300V / 45-500Hz / 800VA (input rating 180-250V)

6415 : Programmable AC Source 0~300V / 45~1000Hz (1500VA)

6420 : Programmable AC Source 0~300V / 45~1000Hz (2000VA)

6430 : Programmable AC Source 0~300V / 45~1000Hz (3000VA)

6460-2 : Programmable AC Source 0~300V / 45~1000Hz (6000VA), output 1Ø, input 3Ø 220V

6460-3 : Programmable AC Source 0~300V / 45~1000Hz (6000VA), output 1Ø, input 3Ø 380V

6463-2 : Programmable AC Source 0~300V / 45~1000Hz (6000VA), output 1Ø or 3Ø Selectable, input 3Ø 220V

6463-3 : Programmable AC Source 0~300V / 45~1000Hz (6000VA), output 1Ø or 3Ø Selectable, input 3Ø 380V

6490-2 : Programmable AC Source 0~300V / 45~1000Hz (9000VA), output 1Ø or 3Ø Selectable, input 3Ø 220V

6490-3 : Programmable AC Source 0~300V / 45~1000Hz (9000VA), output 1Ø or 3Ø Selectable, input 3Ø 380V

A640002 : Remote Interface for Model 6415 / 6420 / 6430 Series (External V Input, RS-232 Interface, GPIB Interface)

A640003 : Remote Interface for Model 6404 / 6408 Series (External V Input, RS-232 Interface, GPIB Interface)

A640004 : Softpanel for Model 6400 Series

A610004 : Universal Socket Center for Model 6415 / 6420 / 6430 Series
