Note: Constant power modes on 3000Ls and 4500Ls. Current available at reduced voltage for 3000Ls, 4500Ls and max
voltage for 6000Ls.
Max RMS Current @ FS Voltage
Frequency Range:
With -HF option: 45 Hz - 2000 Hz
-HF Option
Frequency Range:
3000Ls, 4500Ls, 6000Ls
Standard, -HV: 45 Hz - 5000 Hz
-EHV: 45 Hz - 2000 Hz
All other models:
45 Hz - 2000 Hz
Output Noise
250 mVrms typical (20 kHz to 1 MHz)
Measurements
F < 2000 Hz: See standard Ls specifications.
F > 2000 Hz: See table.
* See standard measurement specifications for notes.
Mode: 1 Phs 15.0 A 30.0 A
V Range V high V low
3000Ls 3 Phs
1 Phs
2.5 A
7.5 A 5.0 A
15.0 A
4500Ls 3 Phs
1 Phs
3.8 A
11.3 A 7.5 A
22.5 A
6000Ls 3 Phs
1 Phs
5.0 A
15.0 A 10.0 A
30.0 A
Parameter Range Accuracy* (±) Resolution
1 ø mode 3 ø mode
Frequency See standard Ls 1 Hz
Phase < 2000 Hz See standard Ls
> 2000 Hz 5° 1°
Voltage (AC) 0 -300 V
< 1000 Hz
> 1000 Hz
0.05% + 250mV
0.1% + 0.1%/KHz + 300 mV 10 mV
10 mV
Current (AC rms) 0 - 50 A 0.5% + 150 mA 0.5% + 50 mA 1 mA
Real Power 0 - 5 kW 0.5% + 9 W 0.5% + 3 W 1 W
Apparent Power 0 - 5 kVA 0.5% + 9 VA 0.5% + 3 VA 1 VA
Power Factor 0.00 - 1.00 0.03 0.01 0.01
Ordering Information
Model Output
Power
Phase
Output
Input
Voltage 1
3000Ls 3 kVA 1/3 208-230V ±10 %
4500Ls 4.5 kVA 1/3 208-230V ±10 %
4500Ls-400 4.5 kVA 1/3 400V ±10%
6000Ls 6 kVA 1/3 208-230V ±10 %
9000Ls 9 kVA 1/3 208-230V ±10 %
9000Ls-400 9 kVA 1/3 400V ±10%
12000Ls 12 kVA 1/3 208-230V ±10 %
