DATA SHEET > NetWave Series 1-phase > 20130304
TECHNICAL DETAILS
MODEL OVERVIEW
1-PHASE NETWAVE-MODELS
NetWave 3
Multifunctional AC/DC source,
3,500VA AC / 4,500W DC
NetWave 7
Multifunctional AC/DC source,
7,500VA AC / 9,000W DC
NetWave 7.x
Multifunctional AC/DC source,
7,500VA AC / 9,000W DC,
with built-in isolation transformer
required to perform tests as per
aircraft (DO-160, Airbus and Boeing)
and military (MIL-STD-704)
standards
TECHNICAL DETAILS
NETWAVE 3
Output voltage
0V - 300V AC (RMS)
0V - +/-425V DC
Output current
12A (RMS) continuous
21A (RMS) short-term (max. 3s)
100A repetitive peak
NETWAVE 7
Output voltage
0V - 300V AC (RMS)
0V - +/-425V DC
Output current
26A (RMS) continuous
47A (RMS) short-term (max. 3s)
200A repetitive peak
NETWAVE 7.2 / NETWAVE 7.3*
Output voltage
0V - 360V AC (RMS)
0V - +/-500V DC
Output current
(@max. 300V AC)
26A (RMS) continuous
47A (RMS) short-term (max. 3s)
200A repetitive peak
* EXTENDED CAPABILITIES FOR NETWAVE 7.3
SourceAC mode
PLL synchronization with other
voltage sources
Trigger channel
Extended trigger functions
Segment "Step"
Ramping of voltage and/or frequency
in constant time windows
Extern mode
Control of the NetWave by an
external control signal
Simple Mode
Optimized control for integration of
the Netwave into existing
automation environments (for
example Matlab)
