VNA Performance Capabilities (MS202x/3xC)
Measurement Parameters S
11
, S
21
, S
22
, S
12
, S
d 1 d 1
, S
c 1 c 1
, S
d 1 c 1
, S
c 1 d 1
Number of Traces Four: TR1, TR2, TR3, TR4
Trace Format Single, Dual, Tri, Quad. When used with Number of Traces, overlays are possible including a Single Format with Four trace overlays.
Graph Types
Log Magnitude
SWR
Phase
Real
Imaginary
Group Delay
Smith Chart
Inverted Smith Chart
Log Mag / 2 (1-Port Cable Loss)
Linear Polar
Log Polar
Real Impedance
Imaginary Impedance
Domains Frequency Domain, Time Domain, Distance Domain
Frequency Start Frequency, Stop Frequency, Center Frequency, Span
Distance Start Distance, Stop Distance
Time Start Time, Stop Time
Frequency Sweep Type: Linear Single Sweep, Continuous
Data Points 2 to 4001 (arbitrary setting); data points can be reduced without recalibration.
Limit Lines Upper, Lower, 10-segmented Upper, 10-segmented Lower
Test Limits Pass/Fail for Upper, Pass/Fail for Lower, Limit Audible Alarm
Data Averaging Sweep-by-sweep
Smoothing 0 to 20%
IF Bandwidth 10, 20, 50, 100, 200, 500, 1 k, 2 k, 5 k, 10 k, 20 k, 50 k, 100 k (Hz)
Reference Plane
The reference planes of a calibration (or other normalization) can be changed by entering a line length. Assumes no loss, flat magnitude, linear phase, and
constant impedance.
Auto Reference Plane Extension Instead of manually entering a line length, this feature automatically adjusts phase shift from the current calibration (or other normalization) to compensate for
external cables (or test fixtures). Assumes no loss, flat magnitude, linear phase, and constant impedance.
Frequency Range Frequency range of the measurement can be narrowed within the calibration range without recalibration.
Group Delay Aperture
Defined as the frequency span over which the phase change is computed at a given frequency point. The aperture can be changed without recalibration. The
minimum aperture is the frequency range divided by the number of points in calibration and can be increased to 20% of the frequency range.
Group Delay Range < 180º of phase change within the aperture
Trace Memory A separate memory for each trace can be used to store measurement data for later display. The trace data can be saved and recalled.
Trace Math Complex trace math operations of subtraction, addition, multiplication, or division are provided.
Number of Markers Eight, arbitrary assignments to any trace
Marker Types Reference, Delta
Marker Readout Styles
Log Mag, Cable Loss (Log Mag / 2), Log Mag and Phase, Phase, Real and Imaginary, SWR, Impedance, Admittance, Normalized Impedance, Normalized
Admittance, Polar Impedance, and Group Delay, Linear Mag, Linear Mag and Phase
Marker Search Peak Search, Valley Search, Find Marker Value
Correction Models
Full 2-Port, Full S
11
, Full S
22
, Full S
11
& S
22
, Response S
21
, Response S
12
, Response S
21
& S
12
, Response S
11
, Response S
22
, Response S
11
& S
22
, One-
Path Two-Port (S
11
,S
21
), One-Path Two-Port (S
22
,S
12
)
Calibration Methods Short-Open-Load-Through (SOLT), Offset-Short (SSLT), and Triple-Offset-Short (SSST)
Calibration Standards’
Coefficients
Coax: N-Connector, K-Connector, 7/16, TNC, SMA, and four User Defined
Waveguide: WG11A, WG12, WG13, WG14, WG15, WG16, WG17, WG18, WG20, and four User Defined
Cal Correction Toggle On/Off
Dispersion Compensation Waveguide correction that improves accuracy of distance-to-fault data by compensating for different wavelengths propagating at different speeds.
Impedance Conversion Support for 50 Ω and 75 Ω are provided.
Units Meters, Feet
Bias Tee Settings Internal, External, Off
Timebase Reference Internal, External (10 MHz)
File Storage Types Measurement, Setup (with CAL), Setup (without CAL), S2P (Real/Imag), S2P (Lin Mag/Phase), S2P (Log Mag/Phase), JPEG
Ethernet Configuration DHCP or Manual (Static); IP, Gateway, Subnet entries
Languages English, French, German, Spanish, Chinese, Japanese, Korean, Italian, Russian, plus one User Defined
