14
High Accuracy Power Meter (Option 0019) requires external USB power sensor.
Conduct precise measurements of CW and digitally modulated transmitters in the field using this VNA Master software mode with a
separately purchased Anritsu USB power sensor. After specifying the center frequency and zeroing the sensor to ensure accuracy at
low power levels, the software offers intuitive operation for absolute and relative readouts in dBm or Watts. Option 0019 supports
the USB Power Sensors in the following table.
Interference Analyzer (Option 0025) (MS203xC models only) (recommend GPS)
Measurements
Spectrum
Field Strength
Occupied Bandwidth
Channel Power
Adjacent Channel Power (ACPR)
AM/FM/SSB Demodulation (Wide/Narrow FM, Upper/Lower SSB), (audio out only)
Carrier-to-Interference ratio (C/I)
Spectrogram (Collect data up to one week)
Signal Strength (Gives visual and aural indication of signal strength)
Received Signal Strength Indicator (RSSI) (collect data up to one week)
Gives visual and aural indication of signal strength
Signal ID (up to 12 signals)
Center Frequency
Bandwidth
Signal Type (FM, GSM, W-CDMA, CDMA, Wi-Fi)
Closest Channel Number
Number of Carriers
Signal-to-Nose Ratio (SNR) > 10 dB
Application Options Impedance (50 Ω, 75 Ω, Other)
Channel Scanner (Option 0027) (MS203xC models only)
Number of Channels 1 to 20 Channels (Power Levels)
Measurements Graph/Table, Max Hold (On/5 sec/Off), Frequency/Channel, Current/Maximum, Dual Color
Scanner Scan Channels, Scan Frequencies, Scan Customer List, Scan Script Master™
Amplitude Reference Level, Scale
Custom Scan Signal Standard, Channel, # of Channels, Channel Step Size, Custom Scan
Frequency Range 150 kHz to 13 GHz
Frequency Accuracy ± 10 Hz + Time base error
Measurement Range –110 dBm to +30 dBm
Application Options Impedance (50 Ω, 75 Ω, Other)
USB Power Sensors (Ordered separately):
PSN50 MA24105A MA24106A MA24108A MA24118A MA24126A
Frequency Range 50 MHz to 6 GHz 350 MHz to 4 GHz 50 MHz to 6 GHz 10 MHz to 8 GHz 10 MHz to 18 GHz 10 MHz to 26.5 GHz
Description
High Accuracy
RF Power Sensor
Inline
Peak Power Sensor
RF
USB Power Sensor
Microwave
USB Power Sensor
Microwave
USB Power Sensor
Microwave
USB Power Sensor
Connector Type N, male, 50 Ω Type N, female, 50 Ω Type N, male, 50 Ω Type N, male, 50 Ω Type N, male, 50 Ω Type N, male, 50 Ω
Dynamic Range
–30 dBm to +20 dBm
(0.001 mW to 100 mW)
+3 dBm to +51.76 dBm
(2 mW to 150 W
–40 dBm to +23 dBm
(0.1 µW to 200 mW)
–40 dBm to +20 dBm
(0.1 µW to 100 mW)
–40 dBm to +20 dBm
(0.1 µW to 100 mW)
–40 dBm to +20 dBm
(0.1 µW to 100 mW)
VBW 100 Hz 100 Hz 100 Hz 50 kHz 50 kHz 50 kHz
Measurand True-RMS True-RMS True-RMS
True-RMS. Slot power,
Burst Average Power
True-RMS, Slot power,
Burst Average power
True-RMS, Slot power,
Burst Average power
Measurement
Uncertainty
± 0.16 dB 1 ± 0.17 dB 2 ± 0.16 dB 1 ± 0.18 dB 3 ± 0.18 dB 3 ± 0.18 dB 3
Datasheet for
Additional
Specifications
11410-00414 11410-00621 11410-00424 11410-00504 11410-00504 11410-00504
Notes:
1) Total RSS measurement uncertainty (0 ºC to 50 ºC) for power measurements of a CW signal greater than –20 dBm with zero mismatch errors
2) Expanded uncertainty with K=2 for power measurements of a CW signal greater than +20 dBm with a matched load. Measurement results referenced to the input side of the sensor.
3) Expanded uncertainty with K=2 for power measurements of a CW signal greater than –20 dBm with zero mismatch errors
