2
AGILENT 8902A MEASURING RECEIVER*
TECHNICAL SPECIFICATIONS
Specifications describe the test set’s warranted performance
and are valid over the entire operation and environmental
ranges unless otherwise noted. All specifications are valid
after a 30-minute warm-up period of continuous opera-
tion, and within the frequency ranges defined below.
Supplemental characteristics are intended to provide
additional information useful in applying the instru-
ment by giving typical, but non-warranted performance
parameters. These characteristics are shown in Italics
and labeled as “nominal,” “typical,” or “supplemental.”
* Shaded text signifies measurements made with the
8902A measuring receiver using the 11793A microwave
converter and 11792A sensor module. With this config-
uration, all standard 8902A specifications apply except
where changes are shown as shaded text.
Frequency Modulation
RATES 1 :
20 Hz to 10 kHz, 150 kHz
≤
f
c
<10 MHz.
20 Hz to 200 kHz, 10 MHz
≤
f
c
≤
1300 MHz.
20 Hz to 200 kHz, 10 MHz
≤
f
c
≤
26.5 GHz.
DEVIATIONS 1 :
40 kHz
peak
maximum, 150 kHz
≤
f
c
<10 MHz.
400 kHz
peak
maximum, 10 MHz
≤
f
c
≤
1300 MHz.
400 kHz
peak
maximum, 10 MHz
≤
f
c
≤
26.5 GHz.
ACCURACY 1, 2, 3 :
FM Accuracy Frequency Range Rates Deviations
±2% of reading 250 kHz – 10 MHz 20 Hz – 10 kHz
≤
40 kHz
peak
±1 digit
±1% of reading 10 MHz – 1300 MHz 50 Hz – 100 kHz
≤
400 kHz
peak
±1 digit
±5% of reading 10 MHz – 1300 MHz 20 Hz – 200 kHz
≤
400 kHz
peak
±1 digit
±1% of reading 10 MHz – 26.5 GHz 50 Hz – 100 kHz
≤
400 kHz
peak
±1 digit
±5% of reading 10 MHz – 26.5 GHz 20 Hz – 200 kHz
≤
400 kHz
peak
±1 digit
For rms detector add ±3% of reading.
DEMODULATED OUTPUT DISTORTION 1, 4 :
THD Frequency Range Rates Deviations
<0.1% 400 kHz – 10 MHz 20 Hz – 10 kHz <10 kHz
<0.1% 10 MHz – 1300 MHz 20 Hz – 100 kHz <100 kHz
<0.1% 10 MHz – 26.5 GHz 20 Hz – 100 kHz <100 kHz
AM REJECTION (50 Hz to 3 kHz BW) 3 :
AM Rejection Frequency Range Rates AM Depths
<20 Hz peak 150 kHz – 1300 MHz 400 Hz or 1 kHz
≤
50%
deviation
<20 Hz peak 150 kHz – 26.5 GHz 400 Hz or 1 kHz
≤
50%
deviation
RESIDUAL FM (50 Hz to 3 kHz BW):
<8 Hz
rms
at 1300 MHz, decreasing linearly with
frequency to <1 Hz
rms
for 100 MHz and below.
<17 Hz
rms'
1300 MHz
c
≤
6.2 GHz.
<33 Hz
rms'
6.2 GHz
c
≤
12.4 GHz.
<49 Hz
rms'
12.4 GHz
c
≤
18.6 GHz.
<65 Hz
rms'
18.6 GHz
c
≤
26.5 GHz.
Supplemental Characteristics:
MAXIMUM FM DEVIATION, RESOLUTION, AND
MAXIMUM DEMODULATED OUTPUT SENSITIVITY
ACROSS AN OPEN CIRCUIT (600
Ω
output impedance) 5 :
Maximum Maximum Demodulated Deviations
Resolution Output Sensitivity ( D F)
100 Hz 0.01 mV/Hz D F
peak
≥
40 kHz
10 Hz 0.1 mV/Hz 4.0 kHz
≤
D F
peak
<40 kHz
1 Hz 1.0 mV/Hz D F
peak
< 4 kHz
0.1 Hz 1.0 mV/ Hz D F
rms
< 0.3 kHz
(rms detector only)
Resolution is increased one digit with 750 µs de-empha-
sis and pre-display on.
The demodulated output signal present at the
Modulation Out/Audio In connector is increased in
amplitude by a factor of 10 with 750 µs de-emphasis.
DEMODULATED OUTPUT DISTORTION 1, 4 :
THD Frequency Range Rates Deviations
<0.3% 150 kHz – 400 kHz 20 Hz – 10 kHz <10 kHz
<0.1% 400 kHz – 10 MHz 20 Hz – 10 kHz <10 kHz
<0.1% 10 MHz – 26.5 GHz 20 Hz – 100 kHz <100 kHz
DETECTORS: +peak, – peak, ±peak/2, peak hold, average (rms
sinewave calibrated), rms.
STEREO SEPARATION (50 Hz to 15 kHz): >47 dB.
1. But not to exceed: 20 kHz rates and 40 kHz peak deviations with 750 µs de-
emphasis filter.
2. Not to exceed for stated accuracy: 50 Hz to 40 kHz rates with rms detector.
3. Peak residuals must be accounted for in peak readings.
4. With 750 µs de-emphasis and pre-display "off," distortion is not specified for
modulation outputs >4V peak. This condition can occur near maximum deviation
for a measurement range, at rates <2 kHz.
5. For optimum flatness, cables should be terminated with their characteristic
impedance.
