13
Enhances the mobility of the chamber,
a n d f a c i l it a t e s lo a d / u n lo a d of
specimens.
L stand can fit under the H stand to
save space.
* Be sure to secure the stand to the floor with
the provided anchor bolts.
・ L stand
SH/SU-221, 241:
W440×H450×D750mm (25kg)
SH/SU-261:
W440×H390×D750mm (21.5kg)
SH/SU-641,
661:
W540×H350×D860mm (28kg)
・ H stand
SH/SU-221, 241, 261:
W630×H1140×D815mm (36kg)
SH/SU-641,
661:
W730×H1140×D925mm (40kg)
Stand Auxiliary water tank circuit (SH)
Used to automatically refill the standard
tank with the auxiliary water tank.
Required water quality:
Conductivity 0.1 to 10μS/cm
Water supply pressure:
4.9 to 19.6KPa (Gauge)
Auxiliary water tank (SH)
Used to refill the standard tank.
Tray for auxiliary tank (SH)
P r e ve n t s w a t e r l e a k a g e d u r i n g
standard tank refill process.
OPTIONS
Additional cable port
Provided in addition / replacement of
the standard cable ports.
・ 25mm diameter
・ 50mm diameter
・ 100mm diameter
・ Flat cable port (W100×H25mm)
* Each cable port is equipped with a silicone
sponge rubber plug.
* Basic specification of the chamber may not be
met when equipped with a cable port.
Cable port rubber plug
Prevents air leakage from the cable
port.
Shelf
Equivalent to standard accessory:
〈SH/SU-221, 241, 261〉
Effective size: W200×D150mm
Load resistance: 500gr.
〈SH/SU-641, 661〉
Effective size: W300×D300mm
Load resistance: 5kg.
Specimen basket
Equivalent to standard accessory.
Material: Stainless steel (5 mesh)
25mm diameter type flat type
L stand
Two chambers stacked
(L and H stands)
■Some photographs listed in this catalog contain Japanese display.
■This product can be customized for your needs. For further information, please contact us.
Right-opening door
Door can be changed for a reverse one
(hinges on the right, handle on the left)
* This option is not compatible with inner glass
door option.
