DATA SHEET > UCS 500N7 > 20120518
TECHNICAL DETAILS
GENERAL DATA
INTERFACES
Serial interface USB
Parallel interface IEEE 488, addresses 1 - 30
Analog output 0 - 10VDC to control an external
transformer
CN interface 15pin SubD connector to control an
external coupling network
Fail inputs DUT monitoring via Fail1 and Fail2
input (one each)
DIMENSIONS
Housing 19", 6HU
Weight Approx. 29kg
MAINS
Supply voltage 115 / 230VAC +10%/-15%
Power
consumption Approx. 75W
Frequency 50/60Hz
Fuses 2xT 2A (230V) or 2xT 4A (115V)
SAFETY
Safety standard EN/IEC 61010
Security circuit Control input (24VDC)
Warning lamp Floating contact (max. 230V/6A)
ACCESSORIES INCLUDED
Mains supply
cable Plug depends on the country of use
DUT supply cable Plug depends on the country of use
DUT adapter Socket depends on the country of
use
Operation manual,
Calibration certificate,
iec.control remote control software
OPTIONS
CNI 503Bx 3-phase coupling/decoupling
networks as per IEC 61000-4-4 and
-4-5 up to 100A per phase
iec.control 1 Remote control and documentation
software, including standard test
routines and reporting capabilities.
www.emtest.com © EM TEST > PAGE 8/9
