DATA SHEET > UCS 500N7 > 20120518
TECHNICAL DETAILS
COMBINATION WAVE / SURGE
SURGE MODULE, VCS/N7
As per EN/IEC 61000-4-5 and
EN 61000-6-1, -6-2
Voltage (o.c.) 250V - 7,000V ± 10%
Pulse front time 1.2us ± 30%
Pulse time to half
value 50us ± 20%
Current (s.c.) Max. 3,500A ± 10%
Pulse front time 8us ± 20%
Pulse time to half
value 20us ± 20%
Polarity Positive, negative, alternating
Counter 1 - 30,000 or endless, selectable
TRIGGER CIRCUIT
Release of pulses Automatic, manual, external
Synchronization 0° - 360°, resolution 1°
Repetition rate Max. 0.5Hz (2s - 999s)
OUTPUTS
Direct Via HV connectors for external
coupling networks (Zi = 2ohm with
optional adapter IMN 2)
Coupling modes As per IEC 61000-4-5:
Line to line with 2ohm
Line(s) to ground with 12ohm
As per ANSI/IEEE C62.41
Line to line with 2ohm
Line(s) to ground with 2ohm
DUT supply AC: 300V/16A; 50/60Hz
DC: 300V/10A
CRO trigger 5V trigger signal for oscilloscope
MEASUREMENTS
CRO Û-monitor 10Vp at 7,000V
CRO Î-monitor 10Vp at 3,500A
Peak voltage 7,000V in the LCD display
Peak current 3,500A in the LCD display
TEST ROUTINES
Quick Start One-line adjustable parameters,
easy-to-use
Standard Test
routines As per IEC 61000-4-5, Levels 1 - 4
As per EN 61000-6-1, -6-2
Manual Standard Test routine
User Test routines Change polarity after n pulses
Change coupling after n pulses
Change voltage after n pulses
Change phase angle after n pulses
Pulsed Magnetic
Field As per IEC 61000-4-9
Test levels 100, 300 and 1,000A/m
Test level steplessly adjustable
under Quick Start
OPTIONS
CNV 504Nx Coupling network for 4 signal/data
lines as per IEC 61000-4-5
CNV 508Nx Coupling network for 8 signal/data
lines as per IEC 61000-4-5
IMN 2 Impedance matching adapter to
match direct output to 2ohm source
impedance
