Table 2
Testing specifications.
Test 4 kV model 6 kV model 6 kV HO model 12 kV model 12 kV HO model
Resistance
Source voltage, maximum: 3,9 V 3,9 V 3,9 V 3,9 V 3,9 V
Source current: 600 mA 600 mA 600 mA 600 mA 600 mA
10 000 to 200 000 : 3% accuracy 3% accuracy 3% accuracy 3% accuracy 3% accuracy
100 to 10 000 : 3% accuracy 3% accuracy 3% accuracy 3% accuracy 3% accuracy
0,2 to 100 : 2% accuracy 2% accuracy 2% accuracy 2% accuracy 2% accuracy
0,002 to 0,2 : 4%, ±1 m accuracy 4%, ±1 m accuracy 4%, ±1 m accuracy 4%, ±1 m accuracy 4%, ±1 m accuracy
Capacitance
Source voltage, maximum: 3,9 V 3,9 V 3,9 V 3,9 V 3,9 V
Source current, maximum: 600 mA 600 mA 600 mA 600 mA 600 mA
Source frequency: 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz
0,001 to 2,6 F at 4 000 Hz: 3% accuracy 3% accuracy 3% accuracy 3% accuracy 3% accuracy
2,6 to 26 F at 4 000 Hz: 5% accuracy 5% accuracy 5% accuracy 5% accuracy 5% accuracy
Inductance
Source voltage, maximum: 3,9 V 3,9 V 3,9 V 3,9 V 3,9 V
Source current, maximum: 600 mA 600 mA 600 mA 600 mA 600 mA
Source frequency: 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz
160 to 5 000 mH at 60 Hz: 3% accuracy 3% accuracy 3% accuracy 3% accuracy 3% accuracy
0,5 to 160 mH at 60 Hz: 2% accuracy 2% accuracy 2% accuracy 2% accuracy 2% accuracy
0,05 to 0,5 mH at 60 Hz: 3% accuracy 3% accuracy 3% accuracy 3% accuracy 3% accuracy
Impedance
Source voltage, maximum: 3,9 V 3,9 V 3,9 V 3,9 V 3,9 V
Source current, maximum: 600 mA 600 mA 600 mA 600 mA 600 mA
Source frequency: 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz 50 to 4 000 Hz
0,15 to 10 000 at 60 Hz: 2% accuracy 2% accuracy 2% accuracy 2% accuracy 2% accuracy
0,01 to 0,15 at 60 Hz: 3% accuracy 3% accuracy 3% accuracy 3% accuracy 3% accuracy
Phase accuracy at 60 Hz: < 2 deg. < 2 deg. < 2 deg. < 2 deg. < 2 deg.
DC tests
Voltage accuracy: 3% 3% – 3% –
Maximum resistance: > 500 G > 500 G – > 500 G –
Accuracy: 5% 5% – 5% –
Minimum resistance: 3 M 5 M – 10 M –
Maximum output current: 5 mA 3 mA – 3 mA –
Over-current trip: 1,4 mA 1,4 mA – 1,4 mA –
Surge
Capacitor size (nF): 40 40 100 40 100
Surge energy: 0,32 J 0,72 J 1,8 J 2,88 J 7,2 J
Short circuit current: 280 A 340 A 450 A 600 A 800 A
65 H load voltage: 4 kV 6 kV 6 kV 12 kV 12 kV
Surge voltage accuracy: 11% 11% 11% 11% 11%
Note: Surge voltage accuracy meets/based on Z540 Standard four times measurement uncertainty (calibrated within 2,5%).
