FM Measurement
Frequency Range:
Standard, Options 006, 007, and 016: 30 MHz to 1 GHz
(usable to 400 kHz)
Option 055: 10 MHz to 1 GHz
(usable to 5 MHz)
Deviation: 20 Hz to 75 kHz
Sensitivity: 2 µV, typically <1 µV (15 kHz IF BW, high sensitivity
mode, 0.3 to 3 kHz BW, 12 dB SINAD for f
c
>10 MHz)
Accuracy: ±4% of reading plus residual FM and noise contribution
(20 Hz to 25 kHz rates, deviation
≤
25 kHz).
Bandwidth (3 dB): 2 Hz to 70 kHz (DC FM measurements also
available)
THD+Noise: <1% distortion rms (for deviation
≥
5 kHz and at a
rate of 1 kHz in a 0.3 to 3 kHz BW)
Input Level Range for Specified Accuracy:
ANT IN: –50 to +14 dBm (0.01 µW to 24 mW)
RF IN/OUT:
Standard: –14 to 48 dBm (40 µW to 60 W)
Option 006: –22 to 40 dBm (6.3 µW to 10 W)
Option 007: –28 to 34 dBm (1.6 µW to 2.4 W)
Option 016: –12 to 50 dBm (6.3 µW to 100 W)
Residual FM and Noise: <7 Hz (0.3 to 3 kHz, rms)
Supplemental Characteristics
Resolution: 1 Hz, f <10 kHz; 10 Hz, f
≥
10 kHz
AM Measurement
Frequency Range:
Standard, Option 016: 10 MHz to 1 GHz (usable to 400 kHz)
Options 006, 007: 30 MHz to 1 GHz
Depth: 0 to 95%
Accuracy: ±5% of reading ±1.5% AM (50 Hz to 10 kHz rates,
modulation
≤
80%)
THD+Noise: <2% rms for modulation
≤
80% AM (at 1 kHz rate
in a 0.3 to 3 kHz BW)
Input Level for Specified Accuracy (levels in PEP):
Antenna: ANT IN:
–50 to +14 dBm (0.01 µW to +14 dBm)
RF IN/OUT:
Standard: –14 to 48 dBm (40 µW to 60 W)
Option 006: –22 to 40 dBm (6.3 µW to 10 W)
Option 007: –28 to 34 dBm (1.6 µW to 2.4 W)
Option 016: –12 to 50 dBm (63 µW to 100 W)
Residual AM: <0.2% in a 0.3 to 3 kHz BW
Supplemental Characteristics
Resolution: 0.05% AM for 0 to 10% AM
0.5% AM for 10 to 100% AM
SSB Measurement
Standard Frequency Range: 300 MHz to 1 GHz
Bandwidth (3 dB): 20 Hz to 70 kHz supplemental characteristics
Distortion and Noise: <3% (at 1 kHz rate in a 0.3 to 3 kHz BW)
TDMA Analyzer Specifications
8920B Opt. 001, 004, 051, 800 ( 8920B + 83206A)
Frequency Range: 824 MHz to 894 MHz
Input Level Range:
RF IN/OUT:
Standard: 1 mW to 60 W continuous (0 to 48 dBm),
100 W (to 50 dBm) for 10 seconds per minute
Option 006: 50 µW to 10 W continuous (–13 to 40 dBm),
15 W (42 dBm) for 10 seconds per minute
Option 007: 40 µW to 2.4 W continuous (–14 to +34 dBm),
4 W (36 dBm) for 10 seconds per minute
Option 016: 1.6 mW to 100 W continuous (2 to 50 dBm),
125 W (+51 dBm) for 10 seconds per minute
Input Frequency Setting Error: ±1 kHz
RX DSP Level Setting Range: –23 to 0 dB full scale
Residual Error Vector Magnitude: <1.3%
Error Vector Magnitude Measurement Accuracy: ±0.4% plus 2%
of reading
Residual Phase Error: <1.0°
Residual Magnitude Error: <0.9%
I/Q Origin Offset Accuracy: ±0.5 dB for values to –40 dBc
Frequency Error Accuracy: ±2.5 Hz plus reference accuracy
AF Analyzer Specifications
Frequency Measurement
Measurement Range: 20 Hz to 400 kHz
Accuracy: ±0.02% plus resolution plus reference accuracy
External Input: 20 mV to 30 Vrms
Supplemental Characteristics
Resolution: 0.01 Hz, f <10 kHz; 0.1 Hz, f <100 kHz; and 1 Hz for
f
≥
100 kHz
AC Voltage Measurement
Measurement Range: 0 to 30 Vrms
Accuracy: ±3% rms of reading (20 Hz to 15 kHz, inputs
≥
1 mV rms)
