10
Absolute Level Measurements
Level: Results of absolute power in watts or dBm are calculated
by adding the ACP ratio from the spectrum analyzer to the carrier
power from the input section RF power detector.
Level Range:
Ant In: N/A
RF IN/OUT:
Standard: 1 mW to 60 W continuous
or to 100 W for 10 seconds per minute.
Option 006 (cellular power option): 50 µW to
10 W continuous, 15 W for 10 seconds per minute.
Option 007 (low power option): 40 µW to 2.4 W
continuous, 4.0 W for 10 seconds per minute.
Option 016 (high power option): 1.6 mW to 100 W
continuous, 125 W for 10 seconds per minute.
Option 055:
Level Range: –137 to –19 dBm into 50 W
Reverse Power: 60 watts continuous, 100 watts for
10 seconds per minute.
W/Option 006 (cellular power option):
Level Range: –137 to –12.5 dBm into 50 W
Reverse Power: 5.0 watts continuous, 7.5 watts for
10 seconds per minute.
W/Option 007 (low power option):
Level Range: –137 to –6.5 dBm into 50 W
Reverse Power: 1.2 watts continuous, 2.0 watts for
10 seconds per minute.
W/Option 016 (high power option):
Level Range: –137 to –21 dBm into 50 W
Reverse Power: 100 watts continuous,
125 watts for 10 seconds per minute.
Dynamic Range: Typical values for channel offsets
Channel Offset Channel BW Dynamic Range
12.5 kHz 8.5 kHz –65 dBc
20 kHz 14 kHz –68 dBc
25 kHz 16 kHz –68 dBc
30 kHz 16 kHz –68 dBc
60 kHz 30 kHz –65 dBc
Absolute Accuracy: Equals the sum of RF power measurement
accuracy found in the RF analyzer section and the ACP typical
relative accuracy of ±2.0 dB.
Option 800, Dual-mode TDMA Cellular Adapter –
TIA/EIA-136 DCCH, IS-54 DAMPS
The 8920B Option 800 includes the 83206A TDMA cellular adapter
attached, tested, and calibrated with the 8920B communications
test set.
Option 801, Dual-Mode Adapter and PCS Interface
For TIA/EIA 136 testing in 800 and 1900 MHz bands. This option
is for ordering convenience. It includes the 8920B with the
83206A attached and pretested together plus the additional unit
83236B PCS interface shipped together.
General Specifications
Dimensions
8920B: 7.5 in.H x 13 in.W x 19 in.D (188 x 330 x 456 mm)
8920B Option 800 (83206A attached): 9.8 in.H x 13 in.W x 19 in.D
(250 x 330 x 456 mm)
Weight (fully optioned)
8920B: 37 lb net (16.8 kg)
Shipping Weight: 61 lb net (27.7 kg)
8920B Option 800: ( 83206A attached) 50 lb net (22.7 kg)
Shipping Weight: 80 lb net (36.3 kg)
Power
8920B:
AC: 100 V to 240 V ±10%, 48 to 440 Hz, nominally 100 watts
DC: 11 V to 28 V, nominally 120 watts
8920B Option 800 (83206A attached):
AC: 100 V to 240 V ±10%, 48 to 440 Hz, nominally 140 watts
General
CRT Size: 7 x 10 cm
Operating Temperature: 0 to +55 °C
Storage Temperature: –55 to +75 °C
Calibration Interval: Two years
Supplemental Characteristics
Leakage: At signal generator output frequency and level <–40 dBm,
typical 8920B leakage is <1.0 µV (2.0 mV for 8920B Option 800)
induced in a resonant dipole antenna one inch from any surface
except the rear panel. Spurious leakage levels are typically <1 µV
in a resonant dipole antenna.
