During board turn-on and system debug, Agilent’s straightforward triggering
capabilities help you quickly narrow in on the root cause of a problem.
You can capture every aspect of your design, from a simple stuck bit to the
complex sequence of events leading up to a timing problem. The intuitive
triggering helps you identify the cause of elusive problems in less time—so
you can get to your solution quickly.
Simple Trigger
Set the trigger according to how you think
about your target signals. Use standard
events, such as rising edge, falling edge
or pattern, to define a trigger event.
These events are accessible via an easy
pull-down menu.
You can set the trigger for an event on the
basis of activity on one or more buses or
signals. Simply select the patterns, edge
or levels for the signals that apply.
When you know what you want to capture,
trigger the way you think
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Qualification selections for bus patterns
Selections for individual signals
