T-BERD 6000 COMPACT OPTICAL TEST PLATFORM
5
Polarization Mode Dispersion (PMD) Testing
– Fast and accurate measuring of PMD delay, PMD coefficient, and second
order values
– An approved and standardized method
– The most compact PMD test solution
– Shock-proof and vibration-proof design (with no moving parts)
– Allows for measurement through multiple amplifiers
– Provides statistics and long-term monitoring
DWDM Maintenance Testing
– Measures channel level, power, and wavelength in the S, C, and L bands
– The most compact DWDM test solution
– 1485 nm to 1640 nm wavelength testing
– High wavelength accuracy
– Shock-proof and vibration-proof design (with no moving parts)
– Provides statistics and long-term monitoring
Combined PMD, WDM, and Spectral Attenuation (SA) Testing
– Supports the qualification of CWDM and DWDM systems, including fiber
attenuation across the full bandwidth spectrum
– The most compact PMD/WDM/SA test solution
– 1260 nm to 1640 nm WDM testing over the full bandwidth spectrum
– A high-performance PMD module
– Obtains 1260 nm to 1640 nm total loss and dB/km values with SA testing
– Shock-proof and vibration-proof design (with no moving parts)
Insertion Loss (IL) and Optical Return Loss (ORL) Testing
– Measures bi-directional insertion loss, optical return loss, and fiber length
– One button automated testing
– Choose three wavelengths from 1310 nm, 1490 nm, 1550 nm, and 1625 nm
– Bi-directional testing capability
– Compatible with the OFI-2000 Multifunction Loss Test Set
Chromatic Dispersion (CD) Testing
– Includes acquisition points around 1310 nm, 1480 nm, 1550 nm, and 1625 nm
for accurate chromatic dispersion from 1260 nm to 1650 nm
– The most compact CD test solution
– Shock-proof and vibration-proof (with no moving parts)
– Access to only one end of the fiber is required
– Sectional analysis capability for troubleshooting
– Integrates a four-wavelength OTDR and a light source
The Right Tool for Any Optical Test
