Built-in VFL,
Pow
er M
eter
,
Loss T
est
Set,
and T
alkset
2
T-BERD 6000 COMPACT OPTICAL TEST PLATFORM
Microphone
(4) Molded Bumpers
(7) Soft Keys
(Context Sensitive)
(5) Direct Access Keys
and Start/Stop
Navigation Key Pad
Removable High-Capacity
Li Ion Battery (8 hours battery life)
Power Meter Visual Fault Locator
AC Input
Headset Optical Talkset/
Light Source High-Speed
Ethernet Port
(2) USB Ports
(Video Inspection Scope Option)
T-BERD 6000 Front Panel
T-BERD 6000 Top Side
The T-BERD 6000 is a highly integrated platform that features a single module
slot, a large high-visibility color screen (with an optional touchscreen display), a
high-capacity Lithium ion battery, an optional video inspection scope (via a USB
port), and optional built-in optical test functions, such as a visual fault locator
(VFL), power meter, and loss test set (LTS).
8.4" Indoor/Outdoor TFT Color
Display, Touchscreen Configurable
