Page 3

Battery: Good

Measured: 406 CCA
Rating: 630 CCA
Volts: 12.45 V
Int. R: 6.72 mOhm
Life: 76%

7. Pressing again will proceed to

Battery Test as shown below.

8. Select the rating system: CCA, SAE, DIN,

JIS#, IEC, EN, CA; according to the battery
rating. If you cannot find its rating then select
Unknown.

9. If the battery is rated in JIS#, refer to the

conversion list provided to convert to CCA
rating before keying into the Analyser.

10. Once you had the system rating in mind,

select and press key and the display
will show:

Key in the battery rating values using the

key for increase or decreases the

values by step of 100 units. For double digits
increase or decrease, use the or key by
step of 5 units each press.

11. Once the rating is confirmed, press

key will start the testing process and will
display the result in less than 5 sec.

RESULTS: Good

‘Good’ indicates the battery in good
condition. ‘Replace’ indicates that the battery
needs to be replaced.

Voltage: 12.45V

This indicates the tested battery voltage
(12.45V). It depends on the stage of charge
on the battery:

CCA (Cold Cranking Amps): 406 CCA

CCA rating is being used here. If other rating
(SAE or DIN or JIS# or IEC or EN or CA)
then it will base on the selected respective
rating to calculate the results.

Int. R (Internal Resistance): 6.72m

Ω

Internal resistance should fall between
2.0m

Ω

~ 15.0m

Ω

for normal condition.

LIFE: 76%

Indicates the battery life expectancy in
percentage.

If the reading is greater than 45%,

RESULT will display Good. Anything less
than 45%, RESULT display Replace.

ROUGH CCA GUIDE

Given below is a rough CCA ratings guide for any
unknown battery model basing on the capacity of the
vehicle:

Vehicle

Capacity

Approximate Battery

CCA Rating

1200 ~ 1600 cc

350 CCA

1600 ~ 2000 cc

500 CCA

2000 ~ 3000 cc

650 CCA

3000 cc and

above

750 CCA

M. Benz over

3000 cc

760 A

Select Rating

CCA

SAE
DIN
JIS
IEC
EN
CA
Unknown

Input Battery Rating

Increase/decrease:

Single digit

⊳ By hundredth

500 CCA

Press [Enter] to
proceed.
