11
Then confirm it by pressing save. Once it had
been saved, the display will change to the language
selected. Press key to exit and get back to
the Main menu screen to continue your test.
PC LINK
2. This analyser is also designed to link with PC
for data storage and printout through normal
printer. To do so, the PC has to install the
driver and the software provided in order to
operate.
3. Select the correct driver for your computer
operating system and double click on the icon
followed by the PC set-up.
4. Now link up BESA with PC. In the Setup
Menu display press key to highlight
“PC Link” and then press key to
activate.
5. To confirm the whether there is
communication; click on [Get Data From] tab
and the Last Test Result will appear. See
example below.
