Alpha Technologies Spectra Series User Manual
Page 56
Preliminary Operating Instructions 56 of 62 AIP SERVICE NUMBER 1-800-863-3364
Circuit Boards for 24 Volt, 48 Volt, and 130 Volt DC Chargers
Description Factory
Part
Numbers
Type of
Part
Symbol
Special Treatments
Standard
No Coating
Fungus
Proofing
Conformal
Seal
Rec.
Spr.
A1
SCR
Driver
22480-00S 22480-01S 22480-02S Y
A2
Control or Optional
Remote Control
22470-00S 22470-01S 22470-02S Y
Circuit
Boards
A3
Optional ALARM I/O Relay
22845-00S
22845-01S
22845-02S
Y
Optional parts
Type of
Part
Symbol Description
PART
#
Rec.
Spr
CC2
Remote Temperature Compensation Sensor Cable
32843S
CC3
Remote DC Voltage Sensor Cable
33339S
CC4
Remote Communication Cable 50ft (15m)
34196S
Remote
parts
Remote Control Panel Kit (Note 1)
34841S
19" (483mm) Rack Flanges
34829S
Optional
Mounting
23" (584mm) Rack Flanges
34832S
Protection
Input Lightning Arrester
33441S
Alarm
Relays
ALARM I/O Relay Board Installation Kit (Note 1)
33733S
Note 1: In these optional kits the circuit boards have no special coating on them. If special coatings are
needed contact the manufacturer.
