Preliminary Operating Instructions 55 of 62 AIP SERVICE NUMBER 1-800-863-3364
130 Volt DC Chargers Only
Description Factory
Part
Numbers
DC Ampere Rating
6
12
18
20
25
50
Type of
Part
Symbol
Cabinet Style
S1
S1
S1
S1
S1
S3
Rec.
Spr.
T1
120/240 Vac
Transformer
22935S 22455S 24105S 24105S 22465S 22945S
Trans.
T1
208 Vac
Transformer
25155S 24945S 24915S 24915S 24825S 25165S
CB1
120 Vac Input
Breaker
31633S 31952S 32924S 32924S 32668S NA
CB1
208 Vac Input
Breaker
31634S 31951S 31952S 31952S 31952S 32428S
AC Circuit
Breakers
CB1
240 Vac Input
Breaker
31634S 31949S 31951S 31951S 31952S 32668S
DC Circuit
Breakers
CB2
DC Breaker
32926S 32664S 23401S 23401S 32792S 32476S
C1
Capacitor 28207S
28207S 23352S 23352S 23352S
23352S
* Note 1
Y
D1
Diode Assembly
28018S 28018S 28018S
Y
Unfiltered
option
V1
Varistor-Resistor
Assembly
32884S 32884S 32884S
23809S 23809S
23809S
* Note 1
Y
C1
Capacitor 28207S
28207S 23352S 23352S 23352S
23352S
* Note 1
Y
C2
Capacitor 28207S
28207S 28207S 28207S 28207S
28207S
* Note 1
Y
D1
Diode Assembly
28018S 28018S 28018S 28018S 28018S
28018S
* Note 1
Y
V1
Varistor-Resistor
Assembly
32884S 32884S 32884S 32884S 32884S
32884S
* Note 1
Y
L3
Filter Choke
24275S 24275S 24275S 24275S 24275S 25845S
Filtered or
Battery
Eliminator
option
R4
Resistor Assembly
NA
NA
NA
NA
NA
33338S
Ratings
Resistors
R2
Resistor Assembly 32802S 32803S 35077S 32804S 32806S 32807S
Bat. Sens.
Resistors
R3
Resistor Assembly 32809S 32809S 32809S 32809S 32809S 32809S
SCR1
SCR Rectifiers
with Heatsink
NA NA NA
NA NA
13716S
* Note 2
Y
Rectifiers
SCR1
SCR Rectifiers
without Heatsink
31608S 31608S 31608S 31608S 31608S NA
Y
Zener
ZD1
Zener 32371S
32371S 32371S 32371S 32371S
32371S
Shunt
S1
Shunt Assembly
32921S 32921S 18696S 18696S 18696S 13324S
Note 1: “The 130 volt 50 amp filtered chargers have two C1 and C2 capacitors and two sets of D1 and
V1. The unfiltered 50 A charger has two C1 capacitors and two of the combined diode, varistor, and
resistor assemblies."
Note 2: “With the 130 volt 50 amp charger it is recommended to replace both SCRs at the same time if
one is shorted or open. The #13716S is for only one SCR."
