Preliminary Operating Instructions 53 of 62 AIP SERVICE NUMBER 1-800-863-3364

24 Volt DC Chargers Only

Description Factory

Part

Numbers

Ampere

Rating

6 12 18 20 25 50

Type of

Part

Symbol

Cabinet

Style S1 S1 S1 S1 S1 S3

Rec.

Spr.

120/240 Vac

Transformer

22905S

22915S

23425S

23425S 22425S 23585S

Trans.

208 Vac

Transformer

25075S

25085S

25095S

25095S 25105S 23565S

CB1

120 Vac Input

Breaker

32658S

31634S

31634S 31633S 31951S

CB1

208 Vac Input

Breaker

32658S

32658S 32658S 31633S

AC Circuit

Breakers

CB1

240 Vac Input

Breaker

32658S

32658S 32658S 31633S

DC Circuit

Breakers

CB2

DC Breaker

32669S

32659S

32661S

32661S 32671S

32476S

Capacitor 32461S

32461S

27843S

27843S 27843S

27843S

* Note 1

Diode Assembly

14786S

28018S

28018S 28018S

28018S

* Note 1

Unfiltered

option

Varistor-Resistor

Assembly

32092S

32092S 32092S

32092S

* Note 1

Capacitor 32461S

32461S

27843S

27843S 27843S

27843S

* Note 1

Capacitor 32461S

32461S

27843S

27843S 27843S

27843S

* Note 1

Diode Assembly

14786S

28018S

28018S 28018S

28018S

* Note 1

Varistor-Resistor

Assembly

32092S

32092S 32092S

32092S

* Note 1

Filtered or

Battery

Eliminator

option

Filter Choke

24265S

24265S 24265S

22785S

Ratings

Resistors

Resistor Assembly

32793S

32794S

35077S

32796S 32797S

35056S

Bat. Sens.

Resistors

Resistor Assembly

32343S

32343S 32343S

32343S

SCR1

SCR Rectifiers

with Heatsink

31608S

31608S 31608S NA Y

Rectifiers

SCR1

SCR Rectifiers

without Heatsink

NA NA NA NA NA

13716S

* Note 2

Shunt

Shunt Assembly

32921S

18696S

18696S 18696S

13324S

Note 1: “The 24 volt 50 amp filtered chargers have two C1 and C2 capacitors and two sets of D1 and
V1. The unfiltered 50 A charger has two C1 capacitors and two sets of D1 and V1.”

Note 2: “With the 24 volt 50 amp charger it is recommended to replace both SCR’s at the same time if
one is shorted or open. The #13716S is for only one SCR.”
