Preliminary Operating Instructions 14 of 62 AIP SERVICE NUMBER 1-800-863-3364
FIGURE 6.1-1: RATINGS AND BREAKERS TABLE
DC output AC input
Rated
DC
Volts
Rated
DC
Amps
Rms.
DC
Amps
DC
Circuit
Breaker
Amps
Optional
Cable
Size
AWG
Rated
AC Input
Volts
Rated
AC
Amps
AC
Frequency
Hz
AC Circuit
Breaker
Amps
48 6 10 15 14 120 only 7 60 or 50 10
48 6 10 15 14 208 only 5 60 or 50 10
48 6 10 15 14 240 only 5 60 or 50 10
48 12 20 30 12 120 only 14 60 or 50 20
48 12 20 30 12 208 only 8 60 or 50 15
48 12 20 30 12 240 only 7 60 or 50 10
48 18 35 50 8 120 only 17 60 or 50 30
48 18 35 50 8 208 only 11 60 or 50 15
48 18 35 50 8 240 only 10 60 or 50 15
48 20 35 50 8 120 only 18 60 or 50 30
48 20 35 50 8 208 only 12 60 or 50 15
48 20 35 50 8 240 only 10 60 or 50 15
48 25 40 60 8 120 only 28 60 or 50 30
48 25 40 60 8 208 only 14 60 or 50 20
48 25 40 60 8 240 only 13 60 or 50 20
48 50 80 90 6 120 only 45 60 or 50 60
48 50 80 90 6 208 only 25 60 or 50 40
48 50 80 90 6 240 only 23 60 or 50 40
130 6 10 15 14 120 only 14 60 or 50 20
130 6 10 15 14 208 only 9 60 or 50 15
130 6 10 15 14 240 only 8 60 or 50 15
130 12 20 25 12 120 only 27 60 or 50 40
130 12 20 25 12 208 only 17 60 or 50 30
130 12 20 25 12 240 only 15 60 or 50 25
130 18 35 40 8 120 only 45 60 or 50 60
130 18 35 40 8 208 only 24 60 or 50 40
130 18 35 40 8 240 only 21 60 or 50 30
130 20 35 40 8 120 only 45 60 or 50 60
130 20 35 40 8 208 only 24 60 or 50 40
130 20 35 40 8 240 only 22 60 or 50 30
130 25 40 60 8 120 only 63 60 or 50 70
130 25 40 60 8 208 only 32 60 or 50 40
130 25 40 60 8 240 only 32 60 or 50 40
130 50 80 90 4 208 only 70 60 or 50 90
130 50 80 90 4 240 only 60 60 or 50 70
Notes: All input AC circuit breakers are of the “high inrush” type to prevent nuisance tripping during power-up.
Wiring and connections must meet the requirements of the National Electric Code, state and local codes
and requirements, and the requirements in this manual.
To connect the input AC voltage, route the AC conduit through the appropriate knockout hole. See
SECTION 6.3. Route the AC wiring to terminal lugs AC1 and AC2 located above the AC breaker as
shown in FIGURE 6.1-2. For proper connection, torque the AC1 and AC2 terminal strip screws to
18 inch pounds (2Nm), and the ground lug screw to 35 inch pounds (4Nm), see FIGURES 6.1-2
and 6.1-3.
