Preliminary Operating Instructions 54 of 62 AIP SERVICE NUMBER 1-800-863-3364
48 Volt DC Chargers Only
Description Factory Part Numbers
DC Ampere Rating 6 12 18 20 25 50
Type of
Part
Symbol
Cabinet Style S1 S1 S1 S1 S1 S3
Rec.
Spr.
T1
120/240 Vac
Transformer
22925S 22435S 23775S 23775S 22445S 23925S
Trans.
T1
208 Vac
Transformer
25115S 25125S 25135S 25135S 25145S 23915S
CB1
120 Vac Input
Breaker
32658S 31633S 31951S 31951S 31951S 32924S
CB1
208 Vac Input
Breaker
32658S 31634S 31634S 31634S 31633S 31952S
AC Circuit
Breakers
CB1
240 Vac Input
Breaker
32658S 32658S 31634S 31634S 31633S 31952S
DC Circuit
Breakers
CB2 DC Breaker 32672S 32662S 32663S 32663S 32673S 32476S
C1 Capacitor 32461S 32461S 27843S 27843S 27843S
27843S
* Note 1
Y
D1 Diode Assembly 14786S 14786S 28018S 28018S 28018S
28018S
* Note 1
Y
Unfiltered
option
V1
Varistor-Resistor
Assembly
32092S 32092S 32092S 32092S 32092S
32092S
* Note 1
Y
C1 Capacitor 32461S 32461S 27843S 27843S 27843S
27843S
* Note 1
Y
C2 Capacitor 32461S 32461S 27843S 27843S 27843S
27843S
* Note 1
Y
D1 Diode Assembly 14786S 14786S 28018S 28018S 28018S
28018S
* Note 1
Y
V1
Varistor-Resistor
Assembly
32092S 32092S 32092S 32092S 32092S
32092S
* Note 1
Y
Filtered or
Battery
Eliminator
option
L3 Filter Choke 24265S 24265S 24265S 24265S 24265S 22785S
Ratings
Resistors
R2 Resistor Assembly 32798S 32799S 35076S 32797S 32801S 34931S
Bat. Sens.
Resistors
R3 Resistor Assembly 32808S 32808S 32808S 32808S 32808S 32808S Y
SCR1
SCR Rectifiers
with Heatsink
31608S 31608S 31608S 31608S 31608S NA Y
Rectifiers
SCR1
SCR Rectifiers
without Heatsink
NA NA NA NA NA
13716S
* Note 2
Y
Shunt S1 Shunt Assembly 32921S 32921S 18696S 18696S 18696S 13324S
Note 1: “The 48 volt 50 amp filtered chargers have two C1 and C2 capacitors and two sets of D1 and
V1. The unfiltered 50 A charger has two C1 capacitors and two sets of D1 and V1.”
Note 2: “With the 48 volt 50 amp charger it is recommended to replace both SCR’s at the same time if one is
shorted or open. The #13716S is for only one SCR.”
