HOW TO READ THE ST MODEL NUMBER CONFIGURATION
The model number describes the options on the charger. Write the model number from the charger ratings specification label
in the spaces provided below. The descriptions shown below will confirm your charger’s configuration. If the charger options
are changed in the field, please make sure to tag the charger with a detailed description of the changes.
A
ST
B C D E F G H I J K
If a space has no option selected, a zero must be inserted.
Box ST Description
Remote Sensing
0 Not Supplied
1 Remote Control Panel
2 Remote Temperature Compensation
3 Remote DC Voltage Sensing
4 Lines 1 & 2
5 Lines 1 & 3
6 Lines 2 & 3
G
7 Lines 1, 2 & 3
Lightning Arrester
0 Not Supplied
H
1 Included
Charging
0 Not Supplied
1 Parallel Charging
I
2 Series Charging (Consult Factory)
Special Treatments
0 None
1 Fungus
Proofing
2 Conformal Seal On Electronic PC
Board
J
3 Lines 1 & 2
Other Options
0 None
1
Lockable enclosure door
2 NEMA 4 enclosure
3 NEMA 12 enclosure
4 19” Rack flanges @ 6.0” from front
5 23” Rack flanges @ 6.0” from front
6 Lines 1 & 4
K
7 Lines 1 & 5
Box ST Description
A 1 1 Phase
Nominal DC Output Voltage
024 24 Vdc
048 48 Vdc
B
130 130 Vdc
Nominal DC Output Current
006 6 Adc
012 12 Adc
020 20 Adc
025 25 Adc
C
050 50 Adc *
Input Voltage
1 120
2
208 (not UL listed)
D
3 240
Filtering
0 Unfiltered E
1 Filtered / Eliminator
Relays
0 No Relays
F
1 Individual Alarm Relay Contact
Board
Note:
* 130 Vdc; 50 Adc is not available in 120 Vac.
SAVE THIS MANUAL:
Keep it in a location where it is available to anyone who may operate
or service the charger.
