1. Installation
14
033-077-C0-002 Rev. B
1.1 BE Installation, continued
1. Remove the lid from the PWE, and set aside. For New PWE,
attach bumpers to the upper door jams (see drawing below).
Align the pole mount strap on the PWE-BE with the mounting
plate on the pole. Lower the BE enclosure onto the top of the
PWE. Verify the flange on the bottom of the BE enclosure
fits over the OUTSIDE of the PWE enclosure on both sides and
the back. Tighten the retaining bolt on the PWE-BE pole mount
strap to secure the BE enclosure to the mounting plate.
1.1.4. BE Mounting
Fig. 1-5 Mounting BE Enclosure
Place rubber 'bumpers' in the slots
located on the sides of the New Style
PWE enclosure.
