14 745-419-C0-002, Rev. B
2.1 Provisioning the Transponder, continued
2.1.3 Transponder Confi guration Using CM Confi g File, continued
The following table lists the OID’s from the MIB for each parameter. In case of
any discrepancy the MIB itself should be considered correct. This is included as a
reference for creating the cable modem confi g fi les.
TLGDHMSInit MIB
PARAMETER OID TYPE VALUE
SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.1.0 IP address Dotted decimal IP Eg. 172.16.3.42
TIME SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.2.0 IP address Dotted decimal IPEg. 172.16.3.42
DISCOVERY
COMMUNITY
1.3.6.1.4.1.2082.5.1.1.1.3.0 Octet String
25 character maxe.g.
DOCSISdefaults to DOCSIS
READ COMMUNITY 1.3.6.1.4.1.2082.5.1.1.1.4.0 Octet String
25 character maxdefaults to MAC
address
READ/WRITE
COMMUNITY
1.3.6.1.4.1.2082.5.1.1.1.5.0 Octet String
25 character maxdefaults to MAC
address
SECURE SNMP 1.3.6.1.4.1.2082.5.1.1.1.6.0 Integer 1 enabled 2 disabled
TRAP SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.7.1.2.1 IP address 1 Dotted decimal IPEg. 172.16.3.42
TRAP SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.7.1.2.2 IP address 2 Dotted decimal IPEg. 172.16.3.42
TRAP SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.7.1.2.3 IP address 3 Dotted decimal IPEg. 172.16.3.42
TRAP SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.7.1.2.4 IP address 4 Dotted decimal IPEg. 172.16.3.42
TRAP SERVER IP 1.3.6.1.4.1.2082.5.1.1.1.7.1.2.5 IP address 5 Dotted decimal IPEg. 172.16.3.42
SECURE HOSTS 1.3.6.1.4.1.2082.5.1.1.1.8.1.2.1 IP address 1 Dotted decimal IPEg. 172.16.3.42
SECURE HOSTS 1.3.6.1.4.1.2082.5.1.1.1.8.1.2.2 IP address 2 Dotted decimal IPEg. 172.16.3.42
SECURE HOSTS 1.3.6.1.4.1.2082.5.1.1.1.8.1.2.3 IP address 3 Dotted decimal IPEg. 172.16.3.42
SECURE HOSTS 1.3.6.1.4.1.2082.5.1.1.1.8.1.2.4 IP address 4 Dotted decimal IPEg. 172.16.3.42
SECURE HOSTS 1.3.6.1.4.1.2082.5.1.1.1.8.1.2.5 IP address 5 Dotted decimal IPEg. 172.16.3.42
Table 2-1, TLGDHMSInit MIB
