Alpha Technologies CXDS-M 600_600-19 - Manual (Page 9)

7
9400002-J0 Rev A
Figure 2 — Example of a distribution system with two BDFBs
Supervisory BDFBs
In a multiple BDFB system, a Cordex system controller is mounted in one of the BDFBs.
Optional cable
support bar
Table A —
Configurations
23" Rack Mount 19" Rack Mount
Model CXDS-M
1200
CXDS-M
600/600
CXDS-M
1200-19
CXDS-M
600/600-19
Part Number 0906xxx-xxx 0908xxx-xxx 0907xxx-xxx 0909xxx-xxx
Description
600/600A
Single Voltage
Common Ground
600/600A
Single Voltage
Split Ground
600/600A
Single Voltage
Common Ground
600/600A
Single Voltage
Split Ground
System Voltage: -24V, +24V and -48V
• Single feed, 600A max
• Dual feed 1200A max
