41 4 Communication
Alpha Technologies
4.3 Menu Tree
• To reach any main or sub menu from the opening menu, type its number and press Enter.
• Detailed descriptions of each menu is given in Sections 4.4 to 4.7.
Menu Tree:
Opening Menu
1 System Parameters
Battery Temperature
11 Start Test
12 Stop Test
2 Input Parameters
Voltage
Current
Volt Amps
Power in Watts
Power Factor
Line Frequency
3 Output Parameters
Output #1
Voltage
Current
Output #2
Voltage
Current
Volt Amps
Power in Watts
Power Factor
Line Frequency
4 Battery Parameters
Voltage
Current
Charger Status
Temperature
5 User Parameters
50 Output Shutdown Setup
52 External Modem Setup
53 Set Test Start (DD:HH:MM=00:00:00)
55 Set Test Frequency (off)
56 Transmit Unsolicited Alarms
58 Set User Security code
59 Set Maintenance Security code
CFR software ver. XX.XX
Micro SerNo XXXXXXXX
EEProm Ver. XXXXXXXXXXX
Power Board SerNo XXXXXXXX
6 -Not Available- (History Logs if IID is
installed)
7 Maintenance Parameters
70 Fast Detect Low Ref
71 Fast Detect High Ref
72 Medium Detect Low Ref
73 Medium Detect High Ref
74 Slow Detect Low Ref
75 Slow Detect High Ref
76 Slow Detect Hys. Lo Ref
77 Slow Detect Hyst Hi Ref
78 Max PLL Slew Rate
79 Battery Warning Ref
Main Menu
Sub Menu
To reach any main
or sub menu, type
its number and
press Enter.
