BeAMS / PLK WM TID

Plank Wall Mount

Technical Installation Data

sections

data chart

single Mounting

2"

roW Mounting

End Section

Standard Cross Section

(1, 2 or 3, T8, T5, or T5HO)

9 7/8"

Nominal

Length

Approx. Weight

A

B

C

D

E

F

1-lamp

2-lamp

3-lamp

4'

17 lbs.

17 lbs.

19 lbs.

47 1/4"

48"

192 5/8"

48 5/8"

45 1/4"

48"

8'

28 lbs.

28 lbs.

31 lbs.

95 1/4"

96"

384 5/8"

96 5/8"

93 1/4"

96"

12'

40 lbs.

40 lbs.

43 lbs.

143 1/4"

144"

576 5/8"

144 5/8"

141 1/4"

144"

5/16"

2"

D

E

B

BottoM VieW

B

**Feed location is typical for any fixture within row. Reference job drawing for job-specific locations.

B

A

Solid Housing

Perforated Strip Housing

Feed (Typ)

3"-4" (Typ)
Either Side

A

Wall Bracket (Typ)

Cable (Typ)

F

F

F

E

3"-4" (Typ)

**Feed (Typ)

Wall Bracket (Typ)

Cable (Typ)

C
