Alera Lighting PPLS - Arch Sensors User Manual
Plank plus liso, Row mounting, Bottom view
Page 1/2 Rev. 08/28/12
Beams / PPLS architecturaL SenSorS tiD
Plank Plus liso
installed architectural Sensors technical installation Data
© 2012 Alera Lighting, a division of Hubbell Lighting, Inc. Because of continuing product improvement programs, Alera Lighting reserves the right to change specifications
without notice. 701 Millennium Blvd. Greenville, SC 29607 / Tel 864.678.1000 / Website www.aleralighting.com
A
R
C
H
IT
E
C T
U R A L S
E
N
S
O
R
S
sections
data chart
single Mounting (typical)
Connection Section
2"
row Mounting
End Cap Option
Cross Section 2T8
97/8"
Nominal
Length
Approx. Weight
A
B
C
D
1-lamp
2-lamp
4'
17 lbs.
17 lbs.
471/4"
48"
192 5/8"
48 5/8"
8'
28 lbs.
28 lbs.
951/4"
96"
384 5/8"
96 5/8"
12'
40 lbs.
40 lbs.
1431/4"
144"
576 5/8"
144 5/8"
5/16"
2"
D
A
B
C
BottoM View
Solid Housing
B
4', 8', 12'
B
A
Note: Suspension data is computed using the standard aircraft cable assembly. The use of rigid stems will yield different data.
Please consult factory for stem data.
Perforated Strip Housing
4', 8', 12'
See technical downloads for appropriate sensor manufacturer detail.
Sensor
Location
Sensor
Location
Sensor
Location
Sensor
Location
Limitations exist for rows containing Installed Architectural Sensors; contact factory for assistance.
