30

Function

Description

PRIVACY

Privacy masking function of up to four zones (free to
configure)

OFF: Privacy masking function deactive

ON:

Privacy masking for all four zones is active

AREA SELECT (1/4~4/4): Zone selection
TOP (0~288): Top limit for the selected area
BOTTOM (0~288): Bottom limit for the selected area
LEFT (0~468): Left limit for the selected area
RIGHT (0~468): Right limit for the selected area
COLOR (1~8): Red(1), light green(2), blue(3),

green(4), light blue(5), purple(6),

white(7),

black(8)

TRANSP (0.0~1.00): Transparency of the masking

MOSAIC (OFF/ON): Mosaic display for the privacy

masking. The impression of
unsharp areas will be produced
for masked areas. The effect is
at best at TRANSP=0.00.

RETURN: Back to main menu
