29
MANUAL Manueller Weißabgleich
LEVEL (0~36): Setting for manual white balance.
PUSH LOCK Push Lock
The white balance measurement will be performed by pressing
the „Enter“ button on the control board, and will be stored.
BACKLIGHT
Function Description
OFF The back light handling is turned off.
BLC The conventional back light compensation function is activated.
(Back Light Compensation)
HLC The function for inversion of too bright image areas into black
color is activated (High Light Compensation). Too bright image
areas will be converted to black areas over certain value (e.g.
car lights).
PICT ADJUST
Function Description
MIRROR Horizontal mirror
OFF: Horizontal image inversion is deactive
ON: Horizontal image inversion is active
BRIGHTNESS Brightness (0~255)
CONTRAST Contrast (0~255)
SHARPNESS Sharpness (0~255): A high value of sharpness could increase
the noise level.
HUE Hue (0~255)
GAIN Gain (0~255): Setting for the maximum internal gain
value.
ATR
Function Description
ATR Settings for the Wide Dynamic Function (Adaptive Tone
Reproduction)
OFF: Wide Dynamic Function deactive
ON: Wide Dynamic Function active
LUMINANCE (LOW/MID/HIGH):
Level of the brightness balance. Dark areas will be
displayed more bright (LOW->HIGH), in addition the
brightness for bright areas will be tried to keep constant.
CONTRAST (LOW/MIDLOW/MID/MIDHIGH/HIGH)
Increasing of image contrast
(LOW->HIGH). A high value can cause detail loss in
dark areas as well as over exposure.
PRIVACY
