28
SHUTTER/AGC
Function Description
AUTO HIGH LUMINANCE: Generell exposure settings
MODE:
SHUT+AUTO IRIS: The exposure control will be done
electronically first (AES). In case the control range is
not appropriate, the auto iris control will be used
additionally.
AUTO IRIS: The exposure will be controlled by auto iris
function of the lens only.
BRIGHTNESS (0~255): Base setting for brightness value
LOW LUMINANCE: Exoposure setting for low light
environment.
MODE: AGC: Activation of automatic gain control.
OFF: Deactivation of automatic gain control.
BRIGHTNESS (x0.25~x1.00): Factor for AGC value.
MANUAL MODE: SHUTTER+AGC: The exposure control will be done
electronically first (AES). In case
the control range is not
appropriate, the auto iris control
will be used additionally.
SHUTTER (1/50~1/10000): Manual exposure setting
AGC (6.0~44.8):
Setting for the maximum gain
value in dB.
White Balance (WHITE BAL)
Function Description
ATW Auto Tracking White Balance
The setting for the white balance function will be performed
dynamically and continuously in the range of 1800~10500K.
SPEED (0~255):
A high value increases the
transfer speed of new ATW
values.
DELAY CNT (0~255): A high value means a bigger
delay time until the next ATW
value detection.
ATW FRAME (x0.50~x2.00): Factor for the detection time of
ATW values (Standard x 1.00,
option for fluorescent light).
ENVIRONMENT: Indoor – Optimized parameter for
indoor usage.
Outdoor – Optimized parameter
for outdoor usage.
PUSH Continuous setting for the white balance with limitation of color
temperature range
USER1 / User 2 User defined white balance
B-GAIN (0~255):
Blue value
R-GAIN (0~255): Red value
ANTI CR Optimized white balance settings for fluorescent light, to avoid
cross color effects
