87
English
Save the account information
Note down your user data and enter this into the configuration of the video server.
7.2 DDNS access via a router
If your network video server is positioned behind a router, then access via DynDNS must be configured in
the router. A description of the DynDNS router configuration for common router models can be found on the
ABUS Security-Center website:
www.abus-sc.com .
The following diagram offers an overview of accessing a video server behind a router via DynDNS.org.
Port forwarding of all relevant ports (at least RTSP + HTTP) must be set up in the router in
order to use DynDNS access via the router.
DynDNS.org
Name Server

http://name.dyndns.org:1026

name.dyndns.org:1026  195.184.21.78:1026

195.184.21.78:1026

195.184.21.78:1026

192.168.0.1
LAN WAN
Internet
