ABUS TVIP40000 - Manual (Page 102)

102
English
13.3 Media settings
You can save up to 5 media settings in the video server.
“Media name” Unique name for the medium.
There are 4 different media types:
 Snapshot (JPEG file)
 Video clip (MP4 format)
 System log (TXT log)
 Custom message (TXT format)
Each medium that you create can only be linked with one event.
Assigning a medium twice results in the incorrect functioning of the video server.
If you wish to use the same media type for two events, you must create two separate media
types beforehand.
Snapshot
“Source” The recording can be made from video streams 1–4.
“Send pre-event image(s)” Number of snapshots before an event.
“Send post-event image(s)” Number of snapshots after an event.
1 9 7 8 6 5 4 3 2
Trigger
Pre-event images Post-event images
