73
English
Please notice that limited access can occur, due to low mobile network bandwidth. We recommend following
settings to optimize the video stream:
Video compression MPEG-4
Resolution 176x144
I Frame
1 Second
Video quality (constant bit rate) 40 Kbit / Second
Audio Compression (GSM-AMR) 12.2 Kbit / Second
If the media player does not support the RTSP authentication, then deactivate this option in the RTSP settings
of the video server.
The RTSP address has to be entered as following:
rtsp:// >:/
How to change the name of the video stream will be explained further on.
Example:
rtsp://192.168.0.99:554/live.sdp
4.8 Connecting to the video server by using eytron VMS Express
The included CD contains the free recording software eytron VMS Express. This software enables you to
connect and display to several IP video servers and record these. Further information can be found in the
manual of the software located on the CD.
