ABUS TVIP52502 Quick operating instructions User Manual
Page 99
99
Pусский
Сетевое подключение (RJ45)
Аналоговый видеовыход
(для сервисного обслуживания)
Аудиовыход
Кнопка перезагрузки
Заземление
Выход аварийного сигнала
Вход аварийного сигнала
Индикатор статуса питания
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Подключение питания 12 В пост. Тока
Аудиовход
RS-485 (не используется)
Quick-Guide-TVIP52502-Buch.indb 99
09.12.13 08:03
