ABUS TVIP52502 Quick operating instructions User Manual
Page 9
9
Deutsch
Netzwerkanschluss (RJ45)
Analoger Videoausgang
(für Servicezwecke)
Audioausgang
Reset-Taste
Masseanschluss
Alarmausgang
Alarmeingang
Statusanzeige für
Spannungversorgung
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Spannungsanschluss 12 VDC
Audioeingang
RS-485 (nicht verwendet)
Quick-Guide-TVIP52502-Buch.indb 9
09.12.13 08:02
