ABUS TVIP52502 Quick operating instructions User Manual
Page 49
49
Dansk
Netværkstilslutning (RJ45)
Analog videoudgang
(til serviceformål)
Audioudgang
Reset-tast
Steltilslutning
Alarmudgang
Alarmindgang
Statusvisning for
spændingsforsyning
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Spændingstilslutning 12 V DC
Audioindgang
RS-485 (anvendes ikke)
