Connexion réseau (RJ45)
Sortie vidéo analogique
(pour maintenance)
Sortie audio
Touche de
réinitialisation
Raccordement
à la masse
Al Sortie d’alarme
armausgang
Entrée d’alarme
Affichage du statut de
l’alimentation électrique
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Connecteur d’alimentation 12 V CC
Entrée audio
RS-485 (non utilisé)
