Page 79
79
Italiano
Collegamento di rete (RJ45)
Uscita video analogica per
operazioni di manutenzione
Uscita audio
Tasto di reset
Collegamento di massa
Uscita allarme
Ingresso allarme
Indicazione di stato per
l’alimentazione di tensione
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Collegamento elettrico 12 V DC
Ingresso audio
RS-485 (non utilizzato)
Quick-Guide-TVIP52502-Buch.indb 79
09.12.13 08:02
