Page 19
19
English
Network access (RJ45)
Analogue video output
(for service purposes)
RS-485 (not in use)
Audio output
Reset button
Ground connection
Alarm output
Alarm input
Status display for
power supply
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
12 V DC power supply
connection
Audio input
Quick-Guide-TVIP52502-Buch.indb 19
09.12.13 08:02
