Polski
Złącze sieciowe (RJ45)
Analogowe wyjście wideo
(do celów serwisowych)
Wyjście audio
Przycisk resetowania
Złącze masowe
Wyjście alarmowe
Wejście alarmowe
Wskazanie stanu
zasilania napięciowego
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Złącze napięciowe 12 V DC
Wejście audio
RS-485 (nieużywane)
