ABUS TVIP52502 Quick operating instructions User Manual
Page 59
59
Svensk
Nätverksanslutning (RJ45)
Analog videoutgång
(för serviceändamål)
Audioutgång
Reset-knapp
Jordanslutning
Larmutgång
Larmingång
Statusvisning för
strömförsörjning
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Spänningsanslutning 12 V DC
Audioingång
RS-485 (används ej)
