ABUS TVIP52502 Quick operating instructions User Manual
Page 39
39
Nederlands
Netwerkaansluiting (RJ45)
Analoge video-uitgang
(voor servicedoeleinden)
Audio-uitgang
Reset-toets
Massa-aansluiting
Alarmuitgang
Alarmingang
Statusweergave voor
voedingsspanning
AUDIO
OUT
MIC
IN
DC 12V
RS-485
LAN(PoE)
ALARM
VIDEO OUT
POWER
1A 1B IN G D+ D-
Spanningsaansluiting 12 V DC
Audio-ingang
RS-485 (niet gebruikt)
Quick-Guide-TVIP52502-Buch.indb 39
09.12.13 08:02
