35
Article number TVCC60011 TVCC60021
Standard PAL
Resolution 650 TVL 690 TVL
Image sensor 1/3“ Sony Exview HAD II
TM
CCD
1/3‘‘ Pixim DPS CMOS
Picture elements (total) 1020(H) x 596(V) Pixel 768(H) x 548(V) Pixel
Picture elements
(effective) 976(H) x 582(V) Pixel 758(H) x 540(V) Pixel
Signal-to-noise ratio 50 dB 50 dB
Minimum light sensitivity
(day) 0.1 Lux @ F1.4, 30 IRE 0.3 Lux @ F1.4, 30 IRE
Minimum light sensitivity
(night) 0.05 Lux @ F1.4, 30 IRE
(B/W mode)
0 Lux @ F1.4, 30 IRE
(IR On)
0.03 Lux @ F1.4, 30 IRE
(B/W mode)
0 Lux @ F1.4, 30 IRE (IR
On)
Automatic day/night
switch Removable IR cut filter (ICR), Color / B/W
IR LEDs 12 x LED [Ø 8 mm]
18 x LED [Ø 5 mm]
Lens 3.3 ~ 12 mm, F1.4
Horizontal viewing angle 89.8° ~ 23.9°
Synchronization Internal
DSS (Frame Integration) - Auto, 0~4x
Automatic Gain Control
(AGC) Max. 32 dB Max. 60 dB
Backlight compensation
(BLC) Automatic
White balance ATW, 1800K ~ 10500K ATW, 2000K ~ 7500K
WDR 46 dB (max.) 120 dB (max.)
DNR (Digital Noise
Reduction) 2D DNR 3D DNR
Iris Level Setup Yes -
Protection class IP66
Video signal FBAS; 1.0V p-p, 75 Ohm
Operating temperature -10°C ~ +50°C
Humidity 0~85%, not condensing
Nominal supply voltage 12 VDC
Power consumption
(without IR) 2.0 W 2.0 W
Power consumption (with
IR) 5.8 W 5.8 W
Dimensions (WxHxD) 88 x 84 x 239.5 mm
Weight 1100 g
