6.5 Camera adjustment
In order to adjust the camera in the right direction you need to loosen the fixing screw with the
supplied hexagon wrench. Remember to fix the screw again after positioning the camera.
Horizontal adjustment
Vertical adjustment
Diagonal adjustment
Please rotate the camera by max. 180 degree.
