ABUS TVCC60000-TVCC60030 User Manual
Page 34
34
Article number
TVCC60020
TVCC60030
Standard
PAL
Resolution
540 TVL
650 TVL
Image sensor
1/3‘‘ Pixim DPS CMOS
1/3’’ Sony Interline Super
HAD II Dual Scan CCD
Picture elements (total)
410.000
1028(H) x 596(V) Pixel
Picture elements
(effective)
390.000
976(H) x 582(V) Pixel
Signal-to-noise ratio
48 dB
50 dB
Minimum light sensitivity
(day)
0.3 Lux @ F1.4, 30 IRE
0.01 Lux @ F1.4, 30 IRE
Minimum light sensitivity
(night)
0.03 Lux @ F1.4, 30 IRE (B/W
mode)
0 Lux @ F1.4, 30 IRE (IR On)
0.005 Lux @ F1.4, 30 IRE
(B/W mode)
0 Lux @ F1.4, 30 IRE (IR
On)
Automatic day/night
switch
Removable IR cut filter (ICR), Color / B/W
IR LEDs
12 x LED [Ø 8 mm]
18 x LED [Ø 5 mm]
Lens
3.3 ~ 12 mm, F1.4
Horizontal viewing angle
89.8° ~ 23.9°
Synchronization
Internal
DSS (Frame Integration)
Auto, 0~4x
Auto, 0~4x
Automatic Gain Control
(AGC)
Max. 24 dB
Max. 32 dB
Backlight compensation
(BLC)
Automatic
White balance
ATW, 2000K ~ 7500K
AWB
WDR
120 dB (max.)
54 dB (max.)
DNR (Digital Noise
Reduction)
DNR
2D + 3D DNR
Iris Level Setup
- -
Protection class
IP66
Video signal
FBAS; 1.0V p-p, 75 Ohm
Operating temperature
-10°C ~ +50°C
Humidity
0~85%, not condensing
Nominal supply voltage
12 VDC
Power consumption
(without IR)
2.0 W
3.5 W
Power consumption (with
IR)
5.8 W
6.8 W
Dimensions (WxHxD)
88 x 84 x 239.5 mm
Weight
1100 g
