ABUS FU8200 Secvest 2WAY Wireless Info Module User Manual
Page 59
59
1. Connecteurs de jacks enfichables pour la sélection du
secteur
2.
Touche pour l’affichage de l’intensité du signal
3. Bornier à vis pour le branchement 12 Volt
4. Potentiomètre
5.
Connecteur enfichable pour l’émetteur de signaux piezo
interne
6. Module de réception sans fil
7. DEL
8. Trou de fixation supérieur
9. Orifices de guidage des câbles
10. Trous de fixation
11.
Câble de raccordement à l’émetteur de signaux piezo
12. Emetteur de signaux piezo
Fig. 2 : vue interne
