ABUS FU8200 Secvest 2WAY Wireless Info Module - Manual (Page 42)

42
signal. If two LEDs or less are lit, then the signal is not
strong enough for reliable operation. The green power
supply LED is always lit.
9. Technical data
Environment class II
Security level 2 EN50131-1 und -3
Protection class IP 54
Operating temperature -10 °C to +55 °C
Humidity 96% relative humidity
Dimensions 123.9 x 123.9 x 40.7 mm
(W x H x D)
Weight 200 g
Power supply 9-14 V DC, 12 V DC nominal
Power consumption 55 ±5% mA (standby)
600 mA (alarm)
Frequency 868.6625 MHz
Display 8 LEDs of different colours
Signals Internal piezo signaller
(max. 110 dB (A) @ 1 m)
Tamper monitoring No
Subject to alterations and errors.
