ABUS SG1660 Optic_acoustic combination signal transmitter User Manual
Page 23
23
Beskrivelse
1
2
2
2
2
3 4 5 6 7
8
9
Stelforbindelse blitz (SG1660)
12V tilslutning blitz (SG1660)
Stelforbindelse sirene
12V tilslutning sirene
Ikke benyttet
Dækselkontakt NC
Dækselkontakt NC
Nedrivningskontakt (intern)
Nedrivningskontakt (intern)
Nedrivningskontakt (intern)
1 Husets dæksel
2 Montagehuller
3 Sirene
4 Befæstigelse
beskyttelses-
afskærmning
5 Befæstigelse husets
dæksel
6 Dækselkontakt
7 Befæstigelse
nedrivningskontakt
8 Skrueklemmerække
9 Beskyttelses--
afskærmning
